UV Filter Rack System

Luminor’s rack-mounted UV/filtration systems offer the convenience of an all-in-one package making installation as simple as connecting the “in & out” of your water supply.

Designed to effectively treat flow rates of 8 & 15 g/pm, Luminor’s rack- mounted UV’s provide the required 5 micron pre-treatment with the option of a full-flow, carbon filter to treat taste and odour.

Installation of a UV system has never been easier with an innovative design that allows for feedwater to enter the filters from either the right or left side of the unit.

Based on Luminor’s modular UV systems, the rack-mounted UV’s offer the flexibility of being “factory ready” to accept all of Luminor’s extras and upgrades, including the UV sensor module, SHERPA, Remote Alarm, solenoid module, cooling fan and Temperature management relief valve. The Blackcomb plug-and-play platform has the most advanced residential controller on the market with a colour screen user interface giving a multitude of screens displaying diagnostics, status, warnings and even QR codes.

Combine this with the capability to fully customize the colour screens with your own dealer information, or different language, and you can easily see how this integrated UV/filter system shines above all others.

If you wish to know more about this product please feel free to reach out using the contact form below:

Specifications

ModelLB4-Z1
LB5-Z1
LB4-Z2
LB5-Z2
LB4-Z12
LB5-Z12
LBH4-Z2
LBH5-Z2
LBH4-Z12
LBH5-Z12
LBH4-Z22
LBH5-Z22
Flow Rate30.3 l/pm30.3 l/pm30.3 l/pm56.8 l/pm56.8 l/pm56.8 l/pm
1st Filter Housing5 micron sediment
LC-105
5 micron sediment
LC-205
5 micron sediment
LC-105
5 micron sediment
LC-205
5 micron sediment
LC-105
5 micron sediment
LC-205
2nd Filter HousingN/AN/AHigh-Capacity
Carbon LC-20C
N/AHigh-Capacity
Carbon LC-20C
High-Capacity
Carbon LC-20C
Port Size1″ MNPT
Electrical90-265V / 50 – 60Hz
Plug TypeBritish Standard
BS 1363 “3” Suffix
Lamp Watts20 (standard
output lamp)
45 (high
output lamp)
Power (Watts)23 (21 @ 230V)57 (48 @ 230V)
Chamber MaterialPolished 316L stainless steel
Reactor Dimensions8.9 x 50.8cm
Controller Dimensions17.2 x 9.2 x 10.2 cm21.7 x 10.8 x 10.2cm
Operating Pressure0.7 – 8.3 bat (10 – 120 psi)
Operating Water Temperature2 – 40oC
Replacement LampRL-420RL-420HO
Replacement SleeveRQ-420
Shipping Weight10.8kg12.2kg19kg11.8kg18.6kg20.9kg
  • An all in one, two filter housing and UV system.
  • LED Lamp countdown.
  • Controller with Lightlock technology to ensure Luminor lamps are used for replacements.
  • Expandable with other Luminor upgrades and extras.
  • Optional full customisation with dealer information on controller.
